Critical Load Exceedance maps

The maps below show the Average Accumulated Exceedance (AAE) of acidity critical loads, and of nutrient nitrogen critical loads, for all habitats combined, and based on UK 5x5 km deposition data averaged for 2012-2014.  .  Although the legends for the two maps are given in different units, the class intervals are equivalent (ie, 7 kg N ha-1 year-1 is equivalent to 0.5 keq ha-1 year-1).  These maps were updated in 2017 following a minor update to the deposition data.

Average Accumulated Exceedance (AAE) of critical loads by CBED 2012-14

(a) Acidity

Acidity Exceedance

(b) Nitrogen

Nutrient N exceedance
